H5000 navigation, instrument and autopilot systems provide accuracy, choice and performance for offshore sailors and racers. Proven over literally millions of ocean miles, H5000 provides a wide range of displays, sensors and processors to provide a complete and personal system.
- Front mounted, low profile design.
- ‘Daisy-chain’ option for ease of installation.
- Clear night lighting.
- High integrity mechanical construction including toughened glass display window.
- Compatible with H5000 and H3000 systems.
|N2K PGNs||128259, 129026|
|NMEA 2000||2 x NMEA2000 Simnet port, 2 LEN|
|Recommended Fuse Rating||5A|
|Supply Voltage||12V DC (10-16V DC)|
|Humidity||Up to 95% RH|
|Operating Temperature Range||-10 to +55ºC (+14 to 131ºF)|
|Compass Safe Distance – Metric, imperial||200mm (7.9″)|
|Dimensions (W x H x D)||115 x 115 x 68mm (4.5 x 4.5 x 2.7″)|
|Weight||0.5 kg (1.1 lbs)|
|Warranty Period||2 Years|
