Simrad NSS9 evo2 combo 4G Radar Kit. No Cartography

Key Features

-Low Profile Glass Design
-More Screen, Less Border
-Widescreen, Multi Touch Display
-Built in High Gain 10Hz GPS/GLONASS
-4 display sizes 7”, 9”, 12” & 16”
-High Brightness Displays
-All new HEROiC Software
-OP40 remote operable
-Chartplotter only versions available
-Networks with existing NSS, NSE, NSO series MFDs
-Networks with all Simrad Performance Modules
-8mm Dash Profile: Family Matched with New MO Monitors
-OP40 Remote Controllable

HEROiC Software

-All new HEROiC Software has been engineered for ease of use and to maximise the benefits of widescreen multi-touch display technology.
-HEROiC has an all new look and feel for Simrad while maintaining the familiar features for the seasoned Simrad user
-HEROiC has been designed for mixed-mode user control to provide a powerful multi touch user interface that can also be operated by a keypad when the sea conditions get challenging
-HEROiC software is more customisable, allowing users to completely configure the system to their needs.
-Personalised Wallpaper
-Fully customisable favourites that can be accessed by a long press of the ‘Home’ key: HEROiC utilizes multitouch gestures for object manipulation and menu access. These types of controls are mainstream in todays Tablet/Smartphone market and very intuitive and easy to adapt to.
-Pinch to zoom Chart, Echo, Radar
-Drag the status bar down from the top of the display to access system controls
-OP40 Remote Controllable

Software Features

NSS evo2 inherits all the existing software feature from NSS RTM 3.0 plus more new for evo2:
-FLIR M-Series camera control
-OP40 Remote controllable
-Dual Radar
-48RPM Radar Support
-BEP C-Zone Integration
–Mercury VesselView Display Integration
–Fusion Link Audio Support – including multiple audio servers
–AIS SARTs
–NMEA Data Logging
–GRIB Weather support
–Adjustable page split ratios and panel layouts
–StructureMap overlay
–BSM2 SW v 1.7 compatible.

• TouchSensible™ Interface with Multi-Touch Control and Rotary Dial with Keypad.
• Internal, Hi-Gain 10 Hz GPS/GLONASS Antenna.
• Widescreen 16:9 Display.
• Pre-Set and Customizable Navigation Panels.
• Bracket-Mount or Flush-Mount Installation.
• Complete Vessel Integration.
• Best-in-Class Performance:
• Fast Processor.
• Bright Screen.
• Easy to Use HEROiC user interface.
• Intelligent Engineering:
• Low Profile (~8mm) Front Mount Option.
• Glass Bridge Look for Any Vessel.
• Full Autopilot Integration Capability.
• GoFree Wireless™ Compatible.
• Networking Capability.
• Optimal Target Separation with Broadband Radar.
• 10 Target MARPA Tracking.

Approvals

Compliance	CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1

Autopilot

Manouevres / Turn Patterns	U-turn, Spiral-turn, C-turn, Zig-zag, Square-turn, Lazy S-turn, Depth contour tracking
Steering Modes	Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. (*Boat type set to Sail)

Connectivity

NMEA 0183 Sentences supported	Input: GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, HDT, HDM, MWV, MWD, DSC, DSE, VDM. (Note AIS sentences are not bridged to or from NMEA 2000)Output: GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, MWV, MWD, TLL, TTM
Bluetooth	No
Ethernet	1 x 5 pin yellow connector x 1 Mbit, max 6 processors on network
N2K PGNs	Receive only59392 ISO Acknowledgement, 59904 ISO Request, 60928 ISO Address Claim, 65285 Temperature with Instance, 65323 Data User Group Request, 65325 Reprogram Status, 65341 Autopilot Mode, 65480 Autopilot Mode, 127245 Rudder, 127251 Rate of Turn, 127257 Attitude, 127488 Engine Parameters, Rapid Update, 127489 Engine Parameters, Dynamic, 127493 Transmission Parameters, Dynamic, 127503 AC input status, 127504 AC Output Status, 127505 Fluid Level, 127506 DC Detailed Status, 127507 Charger Status, 127508 Battery Status, 127509 Inverter Status, 129033 Time & Date, 129038 AIS Class A Position Report, 129039 AIS Class B Position Report, 129040 AIS Class B Extended Position Report, 129794 AIS Class A Static and Voyage Related Data, 129801 AIS Addressed Safety Related Message, 129802 AIS Safety Related Broadcast Message, 129808 DSC Call Information, 129809 AIS Class B “CS” Static Data Report, Part A, 129810 AIS Class B “CS” Static Data Report, Part B, 130313 Humidity, 130314 Actual Pressure, 130576 Small Craft Status, 130842 SimNet DSC Message, 130851 Event Reply, 130817 Product Info, 130820 Reprogram Status, 130832 Fuel Used – High Resolution, 130834 Engine and Tank Configuration, 130838 Fluid Level Warning, 130843 Sonar Status, Frequency and DSP Voltage,Transmit and Receive:61184 Parameter Request/Command, 65289 Trim Tab Insect Configuration, 65291 Backlight Control, 65292 Clear Fluid Level Warnings, 65293 LGC-2000 Configuration, 126208 ISO Command Group Function, 126992 System Time, 126996 Product Info, 127237 Heading/Track Control, 127250 Vessel Heading, 127258 Magnetic Variation, 128259 Speed, Water referenced, 128267 Water Depth, 128275 DistanceLog, 129025 Position, Rapid Update, 129026 COG & SOG, Rapid Update, 129029 GNSS Position Data, 129283 Cross Track Error, 129284 Navigation Data, 129539 GNSS DOPs, 129540 GNSS Sats in View, 130074 Route and WP Service – WP List – WP Name & Position, 130306 Wind Data, 130310 Environmental Parameters, 130311 Environmental Parameters, 130312 Temperature, 130577 Direction Data, 130840 Data User Group Configuration, 130845 Parameter Handle, 130850 Event Command, 130831 Suzuki Engine and Storage Device Config, 130835 SetEngineAndTankConfiguration, 130839 Pressure Insect ConfigurationTransmit only65287 Configure Temperature INSOcts, 65290 Paddle Wheel Speed Configuration, 129285 Route/Waypoint Data, 130818 Reprogram Data, 130819 Request Reprogram, 130828 Set Serial Number, 130836 Fluid Level Insect Configuration, 130837 Fuel Flow Turbine Configuration
NMEA 0183	1 x Transmit, 1 x Receive NMEA 0183, Baud Rates 4800, 9600, 19200, 38400. TX and RX use same baud rate. Optional data cable required (P/N 000-00129-001)
NMEA 2000	1 x NMEA 2000 Micro-C port, 1 LEN
PC Connectivity	No
Video	2 x composite (RCA connectors) inputs. Optional video/ data cable required (P/N 000-00129-001). PAL or NTSC
WiFi	Compatible with WIFI-1 external module

Display

Backlight Color	White
Resolution	480 x 800, WVGA, 15:9
Screen Brightness	1200 nits
Size and Type	9″ optically bonded TFT
Viewing Angles	50° top / 60° bottom, 70° left/right

Electrical

Power Consumption, max.	12W
Power Consumption, min.	4W
Power Consumption, typical	10W
Recommended Fuse Rating	5A
Supply Voltage	9 – 31.2 V DC

Environment

Operating Temperature Range	-15°C to +55°C (5° F to 131° F)
Storage Temperature Range	“-20°C to +60°C (4°F to 140°F)
Waterproof rating	IPX6 and 7

GPS

Correction	WASS, EGNOS, MSAS
GPS Receiver Channels	32 Channels
Position Accuracy	Horizontal Accuracy 3 m (9.8 ft)
Time to First Fix	Cold start 50 sec, Satellite Reacquisition 5 sec
Update rate	10 Hz

MFD

AIS	Receive AIS data over NMEA 2000 or *NMEA 0183 (has to be wired to all NSS processors)
Autopilot	Full auto pilot control and commissioning
Cartography included	World base map
Cartography supported	Insight, Navionics (Gold, NAV+ Platinum+) , C-MAP (MAX N, MAX N+)
Digital Switching	BEP C-Zone
External Storage	2 MicroSD slots, max. 32GB each
GPS	Internal, 10Hz, WASS, MSAS, EGNOS
Internal Storage	90 MB
Multimedia	via SonicHub, SonicHub2, FusionLink, *Sirius (*USA only)
Radar (inc. compatibility)	4G Broadband Radar supplied. Can also work with Halo Pulse Compression Radar, HD Pulse
Sonar (inc. compatibility)	No Integrated echosounder. Compatible with: SonarHub, BSM-3, BSM-2, BSM1 network echo sounders
Weather	SiriusXM via WM-3 (USA only), GRIB
Waypoints, Routes, Tracks	6000 waypoints, 500 Routes with 100 max route points, 50 tracks with up to 12,000 track points.

Physical

Dimensions (W x H x D)	280 x 164 x 107 mm (11 x 6.5 x 4.2″)
Mounting Type	Bracket (Supplied) , panel, flush
Weight	1.507 kg (3.32 lbs.)

Other

Warranty Period

2 Years

Languages

Standard Language Pack: English(US), English(UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, SwedishAsian Language Pack: English (US), Japanese, Korean, Thai, Chinese, Eastern European Language Pack: English (US), English (UK), Bulgarian, German, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Lithuanian, Latvian, Polish, Slovak, TurkishRussia/Ukraine Language pack: English (US), English(UK), German, Spanish, French, Italian, Russian, UkrainianMiddle Eastern Language Pack: English (US), English (UK), Arabic, German, Spanish, Farsi, French, Italian

Brand	Simrad Yachting
Family	NSS Evo 2
Model	NSS9
Class Type	Chartplotter – Multi-Function Display (MFD)
Component	Packaged Systems
Item Type	KIT
