Simrad Pro AD80 Analog Drive Interface for rudder/thruster

Drive interface for analog or proportional control of rudder or thruster using analog voltage or low level current with possibility for frequency, voltage or current angle feedback, digital drive handshake and external mode input.

• Analogue drive interface for additional drives or thrusters.
• Galvanically Isolated analogue output, 4-20mA.

Autopilot

Drive output	Analog +/- 10V or 4-20mA
Engine Drive systems integration	Analog +/- 10V or 4-20mA
Rudder sensor support	RF300, RF45X, RF25N, RF70, RF14XU

Connectivity

NMEA 2000	1x CAN terminal, 1 LEN

Electrical

Power Consumption, max.	200mA (from CAN)
Power Consumption, typical	0,1A
Recommended Fuse Rating	Internal fuse 5A
Supply Voltage	12-16V via CAN

Environment

Operating Temperature Range	-15 to +55C (5 to 131F)
Storage Temperature Range	-30C to +70C (-22F to +158F)
Waterproof rating	IPx2

MFD

Compass Safe Distance – Metric, imperial	1 m (39,37″)

Physical

Dimensions (W x H x D)	211 x 167 x 60mm. (8,29 x 6,58 x 2,36″)
Mounting Type	Bulkhead
Weight	0,5 kg (1,1 lbs)

Other

Warranty Period	2 years

Weight	0,75 kg
Dimensions	23 × 30 × 8 cm
Brand	Simrad Pro
SKU	000-10191-001
Family	AP60/70/80
GTIN	9420024108208
Model	Accessory
Class Type	Autopilot
Component	Processor/Computer/Ethernet Module
Item Type	Main Product
