Simrad Pro IS80 ROT indicator RT81-300

A large format analog display showing the rate of turn of the vessel to either port or starboard in degrees per minute displayed in clear white numbers on a black background.

The IS80 large format range is specifically designed to meet the demands of the professional and coastal commercial user by offering tough easy-to-read instruments that give consistent performance day after day.

• 300 deg/min scale (30 and 120 deg/min options also available).
• Tough, shock-proof 6.8-inch casing.
• Multiple lighting levels with zone lighting.
• Analog (V) interface and SimNet compatible.
• IP66 rated (for front face sealing of a correctly installed instrument – rear case IP20).
• External mounting kit available for full IP66 in exposed external installations.

Approvals

Compliance	IEC/EN 60945

Connectivity

NMEA 2000	1 x NMEA2000 SimNet port, 1 LEN

Display

Backlight Color	Red

Electrical

Power Consumption, max.	5W
Recommended Fuse Rating	5A
Supply Voltage	12/24V DC (10-31V DC)
Humidity	Up to 95% RH

Environment

Operating Temperature Range	-15 to +70ºC (+5 to +158ºF)
Storage Temperature Range	-40 to +80ºC (-40 to +176ºF)
Waterproof rating	IP66

MFD

Compass Safe Distance – Metric, imperial	400mm (1.3′)

Physical

Dimensions (W x H x D)	172 x 172 x 68mm (6.8 x 6.8 x 2.7″)
Mounting Type	Flush
Weight	0.65 kg (1.4 lbs)

Other

Warranty Period	2 Years
Interface	keypad
Languages	English

Weight	0,857 kg
Dimensions	20,328 × 22,234 × 10,164 cm
Brand	Simrad Pro
Family	IS70/80
Model	RT81
Class Type	Instruments
Component	Head/Display
Item Type	Main Product
