Simrad Pro SI80 Signal Interface with 4 NMEA 0183 RX/TX ports, built-in 12V Network supply, 0.6m pigtail cable / female
928,20€
SI80 Signal Interface with 4 NMEA 0183 RX/TX ports, built-in 12V Network supply, 0.6m pigtail cable / female. Including mounting description and mounting accessories. Supply 12-24 VDC.
Detailed Information
Product Description
Product Specifications
Autopilot
| Compass sensor support | NMEA2000, NMEA0183 |
|---|
Connectivity
| NMEA 0183 Sentences supported | Input: AAM, ACK, APB, BOD, BWC, DPT, GGA, GLL, HDG, HDT, HSC, RMA, RMB, RMC, ROT, THS, TNT, VBW, VHW, VLW, VTG, ZDA. Output SI80 Ch1: ACK, ALR, HDG (1Hz) or HDT (1Hz), HTD, RSA (3Hz), THS (3Hz). Output SI80 Ch2: HDG (10Hz) or HDT (10Hz), ROT (3Hz), RSA (5Hz). Output SI80 Ch3: GGA, GLL, HTD, RSA (5Hz), THS (10Hz), TNT, VTG, ZDA. Output SI80 Ch4: ACK, ALR, GGA, GLL, HTD, RSA (5Hz), THS (10Hz) |
|---|---|
| N2K PGNs | 127237, 127245, 127250, 127251, 128259, 128267, 129025, 129026, 129029, 129033, 129283, 129284, 129285, 130850, 130862 |
| NMEA 0183 | 4x Tx, 4x Rx NMEA0183 terminals, 4800 & 38400 Baud |
| NMEA 2000 | 1x CAN terminal, 1 LEN |
Electrical
| Power Consumption, max. | 50mA (from CAN) |
|---|---|
| Supply Voltage | 12/24VDC +30 -10% |
Environment
| Operating Temperature Range | -15 to +55C (5 to 131F) |
|---|---|
| Storage Temperature Range | -30C to +70C (-22F to +131F) |
| Waterproof rating | IPx2 |
Physical
| Dimensions (W x H x D) | 211 x 180 x 60mm (8,29 x 7,08 x 2,36″) |
|---|---|
| Mounting Type | Bulkhead |
| Weight | 0,9 kg (2 lbs) |
Other
| Warranty Period | 2 years |
|---|
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 23 × 30 × 8 cm |
