PC+10 & PC+15 Constant Running Power Units
1.170,00 € – 1.602,00 €
You save
The ML+40 Electro Hydraulic Linear Actuator combines all the elements of an hydraulic circuit in one compact unit. Designed for ease of installation, the unit is supplied with a quick release mounting, tiller bolt and fitting kit.
An optional rudder reference/feedback unit can be mounted directly onto the actuator.
Integral relief valves protect the unit and its mountings from being overloaded.
Terms and Conditions
1ST ORDER DISCOUNT
Claim your initial 5% discount on your first order by registering on the SailRACE community.
CERTIFIED SUPPORT
Get support by officially certified experts. Detail us your refitting needs and we will help you determining the best solution.
Detailed Information
The versatile PC constant running power units use precision made ground gears driven by our ultra-quiet 100W motor and giving outputs of up to either 1.0 or 1.5 L/min nominal flow.
For use in applications on smaller commercial craft, these units come fitted with solenoid directional control valves, zero leakage valves and integral relief valves as standard. Developed specifically for marine autopilot applications in the smaller commercial and pleasure boat market, the PC pumps can be used with single or twin ram systems.
The units are designed to be compatible with both balanced and unbalanced rams and pressurised reservoir type systems.
Both versions are available in 12VDC and 24VDC and are suitable for cylinders 150cc to 400cc.
Technical Data
Weight: 4.5 kg
Finish: Motor – black enamel
Pump: Clear anodised
Solenoid manifold: Black paint to HTS1006
Ports: G1/4 (BSPP) BS2779’73
Motor: 12 VDC or 24VDC 100W
Solenoids: 12VDC or 24VDC 24W
Nominal Pump output:
PC+10 1.0 L/min
PC+15 1.5 L/min
Relief Valve Set 55 Bar
IP Rating: Pump & Coils: IP67
Connectors: IP65
Ignition Protection: BS EN 28846:1993
Location: Under deck, dry compartment only
Orientation: Horizontal or Vertical motor up
Rotation Red lead to positive
Hoses Suitable for working pressure 70 bar.
Minimum burst pressure 100 bar.
Fluid ISO VG10 to VG40 Hydraulic
mineral fluid meeting ISO 6743-4 HV
